From drawing to first article — fast

A long-running division built for the work that cannot wait for a production line: prototypes, first articles, EMS builds and low-batch runs across every metal we forge and machine.

Send a prototype drawing Series capabilities

Why we built it

Prototypes lose their value when they arrive late. So we stopped running them through the production queue and gave them their own division.

The prototype and low-batch market is growing fast — EV platforms, industrial equipment and new mobility products all need small quantities of real, production-grade metal parts long before a tooling order exists. Proto Division exists to win exactly that work.

BDS/PD — What the division does

Four things, done properly

Rapid prototyping

First articles and design-validation parts turned around on dedicated machines, not squeezed between production batches.

Low-batch production

Economical runs in any metal we work — alloy and stainless steel, aluminium, titanium, copper alloys and superalloys.

EMS

Test fixtures and machined mechanical content for electronics, in metals and engineering polymers, shipped assembled.

EMS & fixtures →

High accuracy

The same metrology and quality system as series production — prototypes are measured, not eyeballed.

BDS/PD — Process & material matrix

What we can cut, and in what

The processes a prototype can run through, the materials each one takes and the size it can handle. Lead time is quoted with the price, every time.

CNC turning

Alloy & stainless steel, aluminium, brass, copper, titanium

Ø8–Ø400 mm, up to 750 mm long

Sliding-head turning

Steel, stainless steel, brass, aluminium

Bar up to Ø26 mm

VMC milling

All the metals above, plus engineering polymers

Up to 1200 × 600 × 600 mm

Engineering polymers

Ultem (PEI), Delrin (POM), polycarbonate, ABS, FR4 / G-10

Milled and turned to print

Grinding

Hardened and through-hardened steels

Centreless to Ø150 mm, surface and ID

Wire-cut & spark EDM

Hardened tool steel, steel, copper

Profiles, slots and sharp internal corners

Forged samples

Alloy steel, aluminium

Up to ~5 kg steel, ~2 kg aluminium

Finishing & assembly

Heat treatment, surface finish, fitted hardware

Shipped ready to test

Process	Materials	Envelope
CNC turning	Alloy & stainless steel, aluminium, brass, copper, titanium	Ø8–Ø400 mm, up to 750 mm long
Sliding-head turning	Steel, stainless steel, brass, aluminium	Bar up to Ø26 mm
VMC milling	All the metals above, plus engineering polymers	Up to 1200 × 600 × 600 mm
Engineering polymers	Ultem (PEI), Delrin (POM), polycarbonate, ABS, FR4 / G-10	Milled and turned to print
Grinding	Hardened and through-hardened steels	Centreless to Ø150 mm, surface and ID
Wire-cut & spark EDM	Hardened tool steel, steel, copper	Profiles, slots and sharp internal corners
Forged samples	Alloy steel, aluminium	Up to ~5 kg steel, ~2 kg aluminium
Finishing & assembly	Heat treatment, surface finish, fitted hardware	Shipped ready to test

BDS/PD — The team

A dedicated team, not spare capacity

Proto Division runs on its own skilled manpower — quick-machining specialists, CNC programmers and raw-material sourcing experts who work only on prototype and low-batch work. That is why lead times hold when the drawing changes on Friday.
